SP630E Bluetooth LED Controller, Support PWM COB 5050 Monochrome CCT RGB RGBW RGBCCT Or SPI TTL IC LED Strip WS2811 WS2812B WS2813 WS2814 WS2815 SK6812 LB1934 etc DC5V-24V BanlanX App Music Sync
by UCHARGE
- [Support PWM LED strip] Compatible with PWM LED strips without smart IC chip, including FCOB/COB and SMD 2835/3528/5050/5630/5730. Supports multiple wiring types: 2-Pin (V+ V-) single color/monochrome, 3-Pin CCT (V+ CW WW) tunable white, 4-Pin RGB (V+ R G B), 5-Pin RGBW (V+ R G B W), 6-Pin RGBCCT (V+ R G B CW WW).Note: Monochrome and CCT strips support basic dimming / CCT adjustment only and do not support DIY lighting effects., [Support addressable IC chip LED strip] Supports Addressable IC Chip LED Strip with SPI TTL signal, including 3-Pin (V+ Data GND) and 4-Pin (V+ Data Backup GND) types. Compatible with WS2811 / WS2812B / WS2813 / WS2814 / WS2815 / SK6812 / LB1934 and similar RGB / RGBW / RGBCCT addressable LED strips, including RGBIC COB LED Strip.Not compatible with SK9822 WS2801 etc Data+Clock LED strip.Monochrome and CCT lights do not have the function of DIY lighting effects., [Support SPI+PWM LED Strip] Supports SPI + PWM LED strips at the same time, allowing one controller to run Addressable SPI RGB/RGBIC strips (e.g., WS2811/WS2812B/WS2815) together with PWM non-IC strips such as FCOB/COB single color (2700K/3000K, etc.) or COB CCT tunable. Typical combinations include SPI RGB + 1CH PWM (Monochrome) or SPI RGB + 2CH PWM (CCT).A 12-in-1 LED controller works with multiple LED strip types in one setup to meet different lighting needs., [DIY Custom Lighting Effects + App Control]With the BanlanX App (Bluetooth), you can create DIY custom lighting effects for your LED strip, including customizable colors, dynamic modes, speed, and sensitivity.The app offers 5 control interfaces: dynamic page, static page, music page, custom page and setting page.Timer & Memory Function.Supports up to 5 timers and features power-off memory, which restores your last settings after power is reconnected., [3 control modes] Supports 3 control methods: mobile APP, 2.4G touch remote, and 2.4G touch 86 wall panel. The remote and 86 panel can be set to zone control (up to 4 zones) or unified control (ALL), ideal for multi-area lighting setups.Built-in music lighting effects with 3 music capture methods: phone microphone, player streaming, and built-in high-sensitivity microphone. Note:The APP Grouping function can only be used when all SP630E controllers have exactly the same parameter settings.
